Beauty Equipment Custom Size Lcd Display , 6 O'Clock Negative HTN Lcd Display
Product Details
| Type: | STN LCD Display |
| Storage Temp:: | 0~50, -10~60, -20-+70℃, -30~80 |
| Voltage: | 2.8~5.0 V |
| Connector: | Pin Or Zebra |
| Driving Method: | Static/Dynamic |
| Polarizer Type: | Transflective/Transmissive/Reflective |
| ITEM | CONTENT | DESCRIPTION |
| 1 | Lcd Type | TN, HTN, FSTN, VA, DFSTN ,STN Lcd Display |
| 2 | Outline Size | Customized |
| 3 | VA Size | Custom or 68*65/65mm*1.1T |
| 4 | Viewing Direction | 6 O'clock or 12 O ' clock |
| 5 | Voltage | 2.8V,3.0V, 3.2V,3.6V,4.0V,4.5V,5.0V |
| 6 | Display Mode | Positive or Negative |
| 7 | Backlight | With or without |
| 8 | Operation temp | 0°C TO + 50°C,-10°C TO + 60°C,-20°C TO + 70°C, |
| 9 | Storage temp | - 10°C TO + 60°C, - 20°C TO + 70°C,-30°C TO + 80°C,- 35°C TO + 90°C |
| 10 | Contactor | Pin, Zebra or FPC |
Core features of the product
Customized size design, perfectly adapting to the shape of beauty equipment. For the diverse body structures of beauty devices - whether it's a small portable home hair removal device, facial cleansing device, or a large commercial skin testing device, skin lightening device, or laser skin rejuvenation device, this display supports full-size customization, capable of matching different requirements ranging from 1.5 inches to over 10 inches. Narrow bezels, special cutting designs, etc., can maximize the fit with the device's shell design, enhancing the overall aesthetics and integration of the device.
6 o'clock negative HTN liquid crystal technology, adapting to display requirements in beauty scenarios
6 o'clock viewing angle precise positioning: The 6 o'clock viewing angle refers to the optimal observation direction being directly below the screen, which is in line with the usage scenarios of beauty devices - users are usually positioned directly in front of the device at a lower position, or when the device is placed on a table, users look down to view, this angle can ensure clear and non-reflective display effects, avoiding blurry content due to viewing angle deviation.
Negative HTN liquid crystal advantages: HTN (High Twisted Nematic) liquid crystal is an upgraded type of passive TN liquid crystal, in the negative display mode, the contrast between black background and white text is high, it can still clearly display parameters even in strong light environments (such as bright lights in beauty salons, outdoor sunlight), and can still display key information such as working mode, energy level, countdown in real time; at the same time, it has a fast response speed, no residual images, and can provide real-time feedback of key information such as the device's working mode, energy level, countdown, etc.; moreover, the passive drive design makes its power consumption extremely low, extending the battery life of beauty devices.
High reliability and durability, meeting the working conditions of beauty devices. Beauty devices often come into contact with moisture, residual skincare products, etc. This display adopts a moisture-proof and corrosion-resistant packaging process, with excellent sealing performance at the bezels and interface areas; the operating temperature range covers -20℃ to 70℃, capable of adapting to different usage environments indoors and outdoors; paired with tempered glass panels, it is scratch-resistant and wear-resistant, capable of handling minor collisions and friction during daily operations.
Core application of the product
This customized HTN LCD display is specifically designed for the beauty equipment sector and is widely used in various household and commercial beauty devices. Its core functions mainly focus on operation interaction and data visualization:
For small household beauty devices
Hair removal device: Displays settings adjustment, remaining flash count, skin contact sensing status, and working countdown.
Facial cleansing device: Displays cleaning mode (such as gentle / powerful), working duration, and remaining battery.
Radiofrequency beauty device: Displays radiofrequency energy level, temperature control value, and mode switching status (such as lifting / tightening).
For large commercial beauty equipment
Skin detector: Displays skin moisture, oil content, collagen content, etc. detection data, and simultaneously presents skin problem analysis report.
Photon skin rejuvenation device / laser treatment device: Displays treatment wavelength, energy density, treatment time, probe contact status, and provides real-time feedback on equipment operation parameters, facilitating precise control by operators.
Body shaping instrument: Displays shaping mode, pressure level, and working time, helping users intuitively grasp the shaping process.
Other specialized beauty scenarios can also be applied to devices such as nail light therapy lamps (displaying curing time, light intensity) and scalp care devices (displaying scalp oil detection data, massage level), providing clear and stable display support for various beauty devices.
